explosion-proof Rugged Mobile Computer



explosion-proof Rugged Mobile Computer

Industrial-grade processor, more powerful

MTK 8-core 64-bit 2.0 GHZ high-performance processor,

4GB RAM + 64B ROM large memory, multi-project performance test is smooth without stuttering

Rugged Mobile Computer Rugged Mobile Computer

Ergonomic design, professional and considerate

perfectly integrates ergonomic design with the requirements of professional industrial design. The front features a 5.5-inch large screen, with quick-scan buttons on both sides for easy one-handed operation by either left or right hand. The functional module layout is rational, facilitating users to quickly and effortlessly perform various operations.

explosion-proof Rugged Mobile Computer explosion-proof Rugged Mobile Computer

Enterprise-level data collection capability, enhancing competitive advantage

  • Powerful scanning engine, capable of quickly capturing almost any one-dimensional/two-dimensional barcode
  • 13-megapixel rear camera, capable of capturing clear photos of goods, receipts, etc.
explosion-proof Rugged Mobile Computer explosion-proof Rugged Mobile Computer

NFC reading and writing speed is fast and responsive

  • Equipped with NFC reading and writing function, supporting ISO14443A/B ISO15693 NFC-IP1 NFC-IP2 and other protocol standards.
  • It can be used for close-range device communication and high-security data transmission, with stable and fast connections and low power consumption, meeting the requirements for user authentication, electronic payments, and other applications.
explosion-proof Rugged Mobile Computer explosion-proof Rugged Mobile Computer
Product specifications
    • System Configuration
    • Processor:
      Octa-core 2.0GHz high-performance processor
    • System:
      Android 9.0
    • Memory:
      3GB+32GB (standard), 4GB+64GB (optional)
    • Display and Touch Screen:
      IPS 5.45 inches (1440720) multi-touch full-fit
    • Camera:
      Front 5 million pixels, rear 13 million pixels, supports autofocus
    • SIM Slot:
      Triple slot, supports dual SIM cards or single SIM card + TF card, TF card supports up to 128GB
    • Sensors:
      Gravity, proximity/light sensors
    • Buttons:
      3 buttons: Power button, left Scan button, right Scan button
    • Battery:
      Built-in 3.85V 5000mAh high-performance lithium polymer battery
    • Audio:
      Receiver, speaker, and main and secondary microphones
    • Charging:
      Type-C charging and bottom pin charging, supports 10W fast charging
    • Vibration Motor:
      Built-in vibration motor, supports scanning vibration feedback
    • Scanner Module:
      Supports mainstream scanners such as Symbol 4710, Honeywell 6603, Newland CM60, MINDA ME5066, etc.
    • Communication Interface:
      Type-C1, supports OTG, supports headphone function
    • RF Parameters
    • Wireless Network:
      2G(GSM):B2/B3/B5/B8
      3G(WCDMA):B1/B5/B8
      4G(FDD-LTE):B1/B3/B5/B8/B20
      4G(TDD-LTE):B34/B38/B39/B40/B41
    • Bluetooth:
      Bluetooth 5.0, supports BLE
    • Location:
      GPS/AGPS/GLONASS/QZSS
    • WLAN:
      802.11 ac/a/b/g/n (2.4GHz+5GHz dual-band Wi-Fi)
    • NFC:
      13.56MHz, supports ISO14443A/14443B/15693, etc.
    • Structural Dimensions:
    • Dimensions:
      158mm*76mm*13.8mm
    • Weight:
      240g (including battery)
    • Environmental Parameters
    • Operating temperature:
      -20°C55°C (excluding battery)
    • Storage temperature:
      -30°C70°C (excluding battery)
    • Operating humidity:
      0~95% (non-condensing)
    • Protection level:
      IP68
    • Drop specification:
      1.5-meter multiple drops on concrete
    • Drum drop specification:
      1000 times 0.5-meter drum drop
    • Electrostatic protection:
      15 KV (air discharge), ±8 KV (contact discharge)
    • Development Support:
    • Development language:
      Java
    • Development environment:
      Eclipse/Android Studio
    • Device Accessories:
      • Standard Accessories:
        USB data cable1, fast charging power adapter1, wrist strap1
